Honeywell TC-CCR013 Redundant Control Net Interface Module

Honeywell TC-CCR013 Redundant Control Net Interface Module

Description

Media Type: Dual

Module Type: Redundant Contro lNet Interface Module

l/0 Module Attributes:

• Remove & lnsert Under Power: Standard; modules are automatically sensed and configured upon insertion. field power should be disconnectedbefore removing field terminal blocks.
• LED channel State lndicators: ocated via light pipes at the front of the module. Each digital /0 point has a state LED - green indicates ON,logic side.
• LED Module Status Indicator: Via light pipe, one per module. Tri-color LED represents module status:

  Green: OK

  Red: Fault (number of fashes indicates fault)

  Amber: Override (Force)

• l/0 Labels: Color-coded labels on the module door, removable, with a write-on area for labeling l/0.
• Processor: Micro-controller per module for parallel processing.
• Terminal Boards:

  20 Screw: Barrier or Euro style, tin-plated or gold-plated (for DC connections).

  36 Screw: Euro style, gold plated (Required with certain higher capacity modules).

• Keying: Hardware keying ensures each module matches its terminal block and field wiring.

Features

Dual-Port Connectivity: Supports two independent ControlNet ports.

Fiber Optic Support: includes fiber optic media for extended reach and noise immunity.

Redundant Communication: Ensures reliable data transfer with automatic failover.

Compact Design: Optimized for space efficiency in control systems.

Built-in Diagnostics: Provides real-time status and fault detection.

Robust Performance: Suitable for harsh industrial environments.

Technical Specifications
