Honeywell 51198947-100 HPM Power Supply

Honeywell 51198947-100 HPM Power Supply

Description

The Honeywell 51198947-100 is a reliable HPM power supply designed for Honeywell Distributed Control Systems (DcS). it ensures continuous andstable power for critical industrial processes across various applications,including oil and gas, chemicals, power generation, and manufacturingThis power supply operates from both Ac line voltage (85-264 VAC) and 48V Dc batteries,providing efficient, safe, and robust power for controlsystems in demanding environments.

Features

• AC input，AC/DC output power supply
• Suitable for use in Honeywell UCN(PM,APM or HPM)equipment cabinetsOperates from line voltage 85 to 264 VAC or 48V DC batteriesCE-compliant
• DC output:

       Nominally rated at 25.25 Vdc at 10 amp load from AC line。

       Nominally rated at 24.25 Vdc from 48V battery

       Includes charging circuit for 48V battery

• Includes nominal 6 Vac,line-frequency output at 35 milliamps load for line frequencysynchronization
• Full load operating temperature range:-20°C to +55°C
• Linear derating above 55°C at 0.5 amp/deg C,maximum temperature +65°C
• Outputs can be paralleled with two or more power supplies
• Compliance with applicable directives of the European Economic Community(EEC)

Technical Specifications
