Allen-Bradley 1794-PS1 Power Supply Modules

Allen-Bradley 1794-PS1  Power Supply Modules

Description

Installation Information：

1. Position the power supply module A on a 35 x 7.5mm DIN rail B

(A-B pt. no. 199-DR1; 46277-3; EN 50022) at 30o angle.

2. Rotate the power supply module onto the DIN rail with the top of the rail hooked under the lip on the rear of the adapter module.

3. Press the power supply module down onto the DIN rail until flush. Locking tab (C) will snap into position and lock the adapter module to the DIN rail.

4. If the power supply module does not lock in place, use a screwdriver or similar device to move the locking tab down while pressing the adapter module flush onto the DIN rail and release the locking tab to lock the adapter module in place. If necessary, push up on the locking tab to lock.

5. Connect the power supply wiring as shown under “Wiring.”

Technical Specifications
