Allen-Bradley 1794-IE4XOE2 4 Input/2 Output Analog Module

Allen-Bradley 1794-IE4XOE2 4 Input/2 Output Analog Module

Description

FLEX I/O analog input, output and combination modules are block transfer modules that interface analog signals with any Allen-Bradley programmable controllers that have block transfer capability. Block transfer programming moves input from the module’s memory to a designated area in the processor data table, and output data words from a designated area in the processor data table to the module’s memory. Block transfer programming also moves configuration words from the processor data table to module memory.

Analog Combination Module, 4 Inputs/2 Single-Ended Outputs：

Cover a wide electrical range

Densities range from 8...32 points

Isolated inputs or outputs, protected outputs, electronic fusing, or diagnostics available on some modules

Removal and Insertion Under Power (RIUP) lets you replace modules and make cable connections while the system is in operation

FLEX-I/O XT™ extreme environment modules are rated for -20...70 °C (-4....185 °F) and are compatible with the ControlLogix-XT™ extreme environment system. Contact NHP for further information.

Each I/O module requires a terminal base for connection points for I/O wiring

Wire directly from sensor to terminal base of the Flex™ I/O module and eliminate the terminal strip

Conformally coated modules are available, please contact NHP for further details
